Did you ever experience car engine problems such as smoking, loss of power, or hesitation? If so, it could be a pain not knowing what’s causing this engine problem and what exactly the problem is for that matter. What happens is that your main relay can go bad. If this happens, you might be seeing smoke when you start your car. In some cases, you’ll have a hard time starting your engine while some won’t even be able to start their cars. That’s why here you will learn how to troubleshoot your car engine when such problems occur. As various cars or models and makes, there could be different locations of the parts that we will be discussing here. However, this is a broad or general take that will go well with most cars.
Like any other regular person, one wouldn’t want to spend extra on unexpected expenses such as car repairs. Who doesn’t want to save up as much as they can to spend their money on more important things and to spend some on personal luxuries? That’s why this guide will help you troubleshoot your car on your own without having to pay for a car mechanic. At the same time, getting a right diagnose the first time will help you save money and time as well. You don’t need to replace anything right away because chances are, it might not be the problem. We have to know which one is the crook before jumping into conclusions. After all, you don’t want to buy something that you’re not going to use, right? Follow the steps to know how to troubleshoot your car engine on your own.
-
First, locate the main relay of your car’s engine and remove it.
-
Find the battery positive terminal and attach it to the number 4 terminal. On the other hand, the battery negative terminal must be attached to the number 8 terminal of the main relay. Now, check continuity between the number 5 and the number 7 terminals. If there is continuity, proceed to the next. However, if there is no continuity between terminals number 5 and number 7, then replace the relay and test it out.
-
Since there is no continuity between number 5 and 7 terminals, you’ll have to attach the battery positive terminal to number 5 terminal. On the other hand, attach the number 2 terminal to the battery negative terminal. Now, you have to check for continuity between number 1 and 3 terminals of the main relay. If again there is continuity, proceed to the next step. However if there is none, replace your relay and test it out.
-
Lastly, it’s time to attach number 3 terminal to the battery positive terminal while the negative terminal should be attached to number 8 terminal of the main relay. Now, it’s time to check continuity between the number 5 and number 7 terminals again. If there is, then this means your main relay is not the problem. It means it is working just fine. There are other things to check like the fuel pump or the wiring harness towards the pump. If there’s no continuity, then you should replace your main relay and then test it out.
